GLIMEK SD-300 Suction Dough Divider
The Glimek SD300 is a high-quality, heavy-duty suction-fed dough divider with 1- or 2-pocket operation, offering flexible capacity from 750 to 3000 pieces/hour and precise, gentle dough handling. Built for durability and easy cleaning, it features stainless steel construction, touchscreen controls, and top-tier safety with an auto-stop hopper function—ideal for medium to large commercial bakeries.
Overview
- Weight range: 1-pocket 150 to 2300 grams, 2-pocket 40 to 1000 grams
- Variable speed with frequency converter
- Capacity: 1-pocket from 750 up to 1500 pieces per hour, 2-pocket from 1500 up to 3000 pieces per hour
- Dough knife in stainless steel
- Unique emptying function (hopper reaches down to the dough knife)
- Gentle dough handling
- Dough chambers in high quality Ni.resist steel ensure high weight accuracy and long durability
- PLC touch screen
- Heavy duty construction
- 100 liter stainless steel hopper as standard
- 225 liter stainless steel hopper (optional)
- Non stick coated hopper (optional)
- Easy handling and cleaning since all covers are in stainless steel and removable
- 11 liter oil reserve, easy to fill
- Stainless steel execution
- Available with left or right outfeed
Technical Specifications
Capacity range:
2-pocket: 1500-3000 dough pcs/h
1-pocket: 750-1500 dough pcs/h
Weight range, subject to capacity and dough characteristics:
2-pocket SD300: 40 – 400 gr
1-pocket SD300: 100 – 1000 gr
2-pocket SD300 XL: 150 – 1150 gr
1-pocket SD300 XL: 250 – 2300 gr
PLC control with touch screen for:
– Speed control (frequency converter).
– Weight reference scale.
– Counting/count down.
– Separate control for second outfeed belt.
Fuse (amp): 16A
Power supply: 1.5 kW
Measurements
