JAC Bread Slicer Model Chute 450
- Easy loading & changeover – Gravity-fed loaves, front rollers for smooth handling, and automatic changeover with built-in safety features.
- Ergonomic delivery – Sliced loaves delivered at operator height, with crumb tray for easy cleanup.
- Safe & sustainable – BPA-free satin paint, energy-efficient curing, and standard NEMA 5-15P plug.
New
Overview
The Chute has been designed to cut loaves with ease and a sustained rate. The loaves are fed in successively at a sustained rate simply by gravity.
- Front loading area: The loading area consists of rollers on ball bearings to automatically direct loaves to the loaf changeover area. Given that it is located facing the operator, this simplifies the handling of loaves considerably. It is not necessary to make adjustments for different loaf formats, as the slicer adapts, saving you time and improving ergonomics.
- Secure loaf changeover area: The changeover area transfers the loaf between the loading table and the cutting table. Every time a loaf is transferred, the changeover area revolves to position it on the cutting area. This area is safe thanks to the cells which prevent it from operating if the operator inserts his hand or anything else. A mechanical barrier blocks the transfer of other loaves during changeover.
- Sliced loaf delivery area: The delivery area is located at the correct height to facilitate the handling of loaves sliced. As it is provided with holes, any crumbs fall into the recovery tray.
- Plug configuration: NEMA 5-15P
- BPA-free paint: 100% BPA-free satin paint (Bisphenol A): safer for you, gentler on the planet. Its low-temperature curing process significantly reduces energy consumption. Available in three solid colours: white, black or grey.
Specifications
| Max. loaf dimensions in in (L x H) | 17.3” x 6.3” |
| Motor power in kW | 0.49 |
| Type of motor | 1ph/120V/60Hz/7.3A |
| Plug configuration | NEMA 5-15P |
| Net weight in lbs | 507 |
